Multi-step pipelines.
ComfyUI-compatible JSON.

Workflows let you chain generation steps — prompt conditioning, image generation, video synthesis, remixing — into a single replayable pipeline defined in a JSON file that follows the ComfyUI node-graph schema. Run them from the GUI toolbar or headlessly from the terminal with tt-ctl workflow run.

What is a workflow?

A workflow is a directed acyclic graph of nodes. Each node does one thing — load a model, generate an image, polish a prompt, convert a file — and passes its output to the next node as an input. The graph is stored as JSON and is replayable, shareable, and version-controllable.

Workflow vs plugin

A plugin is a single generator — it takes parameters and produces one artifact. A workflow is a multi-node pipeline that may invoke several plugins in sequence, carry intermediate results between steps, branch on conditions, and produce multiple output artifacts. Plugins are the atomic units; workflows are the compositions.

Supported class_types

The ⚙ Workflow toolbar button

Click the ⚙ Workflow button in the main toolbar to open the workflow panel. The panel is divided into three zones that cover the full lifecycle: selecting a spec, supplying parameters, and reviewing what ran.

The 1964 World's Fair workflow

The worlds_fair_1964.json workflow ships as a built-in example. It demonstrates a complete multi-step pipeline: algorithmic prompt generation, LLM conditioning, image synthesis, and video generation — all chained together with intermediate artifact handoff.

What it produces

A short video — 5 seconds at 24 fps — depicting a stylised scene from the 1964 New York World's Fair. The pipeline generates a landscape SVG as visual reference, conditions a video prompt from it, and submits the prompt to Wan2.2. The entire run takes approximately 12 minutes on a QB2 (P300x2) system.

Node graph — six nodes, left to right

Node colors: teal = input · gold = processing · green = model inference · pink = output/save

Node 1 · input SeedPhrase

Literal text: "1964 New York World's Fair, Unisphere, monorail, optimistic futurity, late afternoon sun"

→ step1-seed.jpg · TTLGTextToImage · ~3s

→

text → nodes 2 and 3

Node 2 · ArtGenNode landscape plugin

plugin_name: "landscape" · palette: "golden" · style: "retro-futurist"
theme input wired from node 1's text output

"a large crowd of people walking around a large sphere"

→ TTLGCaptionImage output · BLIP-2 · ~1.2s

→

SVG file → node 4 as visual reference

Node 3 · PromptConditioner LLM polish

model: "qwen3-0.6b" · style_hint: "cinematic, warm-toned, wide angle"
Expands the seed phrase into a full video generation prompt

→ step3-foreground.png · TTLGRemoveBackground · transparent PNG · ~4s

→

polished text → node 5

Node 4 · FFmpegExtractFrame SVG rasteriser

Converts the landscape SVG to a 960x540 PNG via rsvg-convert and ffmpeg.
Produces an optional seed image for image-to-video. Skipped if T2V is selected.

→ step4-depth.png · TTLGEstimateDepth · grayscale depth map · ~2s

→

PNG path → node 5 seed_image input

Node 5 · VideoGenNode Wan2.2-T2V-A14B

model_name: "wan2.2" · num_frames: 121 · server_url: "http://localhost:8000"
Receives polished prompt from node 3. Seed image from node 4 is optional.

"a large crowd of people walking around a large sphere — 1964 World Fair, retro-futuristic, Kodachrome, cinematic, warm-toned, wide angle, late afternoon sun"

→ TTLGPromptCompose · composed video prompt · ~0.1s

→

video file → node 6

Node 6 · SaveImage Write to history

filename_prefix: "worlds_fair_1964"
Writes to the history store with full node-graph provenance as metadata

→ step6-video-frame.jpg · TTLGImageToVideo · MP4, 121 frames · ~90s

User-facing parameters

The workflow exposes three parameters in zone 2 of the toolbar panel:

Running it from the terminal

# Run with default parameters
tt-ctl workflow run worlds_fair_1964

# Override palette and style hint
tt-ctl workflow run worlds_fair_1964 \
  --param palette=volcanic \
  --param style_hint="moody, low-contrast, fog"

# Validate the graph without running anything
tt-ctl workflow run worlds_fair_1964 --dry-run

Five world's fairs — one pipeline

The same workflow JSON ran on five different prompts: 1964 New York, 1939 New York, 1893 Chicago, 1970 Osaka, and 1967 Montreal. Each produced a seed image, a video, and a poem image. Here's what came out.

1964 New York

seed image · 230KB

1939 New York

seed image · 129KB

1893 Chicago

seed image · 253KB

1970 Osaka

seed image · 200KB

1967 Montreal

seed image · 138KB

1964 New York

video frame · 1.4MB mp4

1939 New York

video frame · 880KB mp4

1893 Chicago

video frame · 1.3MB mp4

1970 Osaka

video frame · 1.1MB mp4

1967 Montreal

video frame · 808KB mp4

1964 New York

poem image · 188KB

1939 New York

poem image · 88KB

1893 Chicago

poem image · 168KB

1970 Osaka

poem image · 228KB

1967 Montreal

poem image · 96KB

Total pipeline time: ~45 min wall time · ~3 min pure inference · 30 artifacts · 1 playlist

Write your own workflow JSON

A workflow is a single JSON file. Drop it in ~/.config/tt-local-gen/workflows/ and it appears in the spec picker immediately — no restart required.

Minimal 2-node example

This workflow takes a theme string, runs the verse art generator plugin, and saves the result to the history store. Two nodes, one connection.

{
  "x-ttlg-params": {
    "theme": {
      "type": "string",
      "label": "Theme",
      "default": "the last train",
      "description": "What the verse is about"
    }
  },

  "nodes": {

    "1": {
      "class_type": "ArtGenNode",
      "_meta": { "title": "Generate verse" },
      "inputs": {
        "plugin_name": "verse",
        "args": {
          "form":  "haiku",
          "theme": ["x-ttlg-param", "theme"]
        }
      }
    },

    "2": {
      "class_type": "SaveImage",
      "_meta": { "title": "Save to history" },
      "inputs": {
        "images":          ["1", 0],
        "filename_prefix": "my-verse"
      }
    }

  }
}

How to build one — step by step

1. 1

   Declare user parameters in x-ttlg-params

   Each key becomes a form field in zone 2 of the toolbar panel. Supported types: string, integer, number, boolean, enum (renders as a dropdown), and file (renders as a file picker). Set a default to pre-fill the form. Set "required": true to block the Run button until the field is filled in.

2. 2

   Reference a parameter inside a node

   Use the two-element array ["x-ttlg-param", "param_name"] wherever you want the runtime to substitute the user-supplied value. This is analogous to how ComfyUI uses [node_id, slot] tuples for node-to-node connections — the same syntax, a different first element.

3. 3

   Wire node outputs to downstream inputs

   Connect one node's output to another's input with a ["node_id", output_slot] tuple — the standard ComfyUI convention. ["1", 0] means "the first output of node 1". The runtime resolves these references at execution time, respecting topological order.

4. 4

   Add a _meta.title to every node

   Titles appear in the zone-3 run history log and in dry-run output. Without them, nodes are identified only by their numeric key, which makes debugging failure reports substantially harder. One line per node; always worth it.

5. 5

   Validate with --dry-run before the real run

   tt-ctl workflow run my-workflow --dry-run validates the graph structure, checks all node references resolve, prints the resolved execution order, and flags which nodes require an active inference server. No models are called. Costs nothing to run repeatedly.

tt-ctl workflow commands

All workflow operations are available headlessly via tt-ctl. The CLI and GUI share the same workflow engine — running a workflow from the terminal produces the same artifacts as clicking Run in the toolbar.

Usage examples

# See all available workflows
tt-ctl workflow list

# Run the built-in 1964 World's Fair example with defaults
tt-ctl workflow run worlds_fair_1964

# Override palette and request fewer frames (faster run)
tt-ctl workflow run worlds_fair_1964 \
  --param palette=arctic \
  --param num_frames=33

# Validate a new workflow without running it
tt-ctl workflow run my_workflow --dry-run

# Show the JSON for a built-in workflow
tt-ctl workflow show worlds_fair_1964

# See the last 10 runs across all workflows
tt-ctl workflow history

# Inspect per-node timings for a specific run
tt-ctl workflow history run-2026-05-29-143201

Where to put workflow files

Both locations are scanned at startup. A user-installed workflow overrides a built-in with the same filename stem.
