Installing

Prerequisites

TT-NN Visualizer requires data generated from TT-NN to analyze.

Follow instructions for setting up TT-Metalium and TT-NN.

Memory reports

A memory report is the db.sqlite database TT-NN writes for a run, alongside its config.json. Despite the name it holds more than memory: it also records the op graph, tensor flow, Python stack traces and, with comparison mode on, comparison results.

Earlier releases called it the profiler report, and some setting names still say profiler. Both names mean the same db.sqlite report. It is unrelated to tt-metal’s device profiler and Tracy, whose output feeds the performance report. The --memory-report-path option was once --profiler-path, which still works but is deprecated.

Recommended pytest config when generating your data:

export TTNN_CONFIG_OVERRIDES='{
    "enable_fast_runtime_mode": false,
    "enable_logging": true,
    "report_name": "YOUR REPORT NAME",
    "enable_detailed_buffer_report": true,
    "enable_detailed_tensor_report": false,
    "enable_graph_report": true,
    "enable_graph_python_stack_traces": true,
    "enable_comparison_mode": false
}'

Configuration Option

Description

enable_fast_runtime_mode

Disable fast runtime mode to ensure all operations are properly traced. Must be disabled to enable logging.

enable_logging

Synchronizes main thread after every operation and logs the operation. Must be enabled.

report_name

Prefix of the folder name where the memory report is output. Must have a value for data to be output to disk.

enable_detailed_buffer_report

Enable to visualize the detailed buffer report after every operation. Needed for full buffer information.

enable_detailed_tensor_report

Enable to visualize the values of input and output tensors of every operation. Data not used by the visualizer.

enable_graph_report

Generates an SVG visualization of the computation graph and enables automatic report generation with pytest. Must be enabled.

enable_graph_python_stack_traces

Capture the Python stack trace at each operation invocation and store it alongside the graph. Required for the visualizer’s per-operation stack trace and source-file view.

enable_comparison_mode

Enable to test the output of operations against their golden implementation. Optional, not always available on models.

To run a test with custom input data, you can use the following command with suitable values for input-path:

pytest --disable-warnings --input-path="path/to/input.json" path/to/test_file.py::test_function[param]

The final output should be a folder within ${TT_METAL_HOME}/generated/ttnn/reports/ which should include at least a db.sqlite file (config.json is optional for the visualizer). The report is created automatically when running TT-Metal model demos and tests with pytest, provided enable_logging is true, report_name has a value, and enable_graph_report is true. (enable_comparison_mode also triggers generation, but it is not a substitute — see the table above.)

Important: every one of those conditions fails silently. With any of them unset you get no report and no error, and not even an empty folder. report_name is the one most often missed — always set it explicitly, for tests as well as model demos.

Memory report files

The topology view expects cluster_descriptor.yaml in that same folder. If it is missing, see Missing cluster descriptor.

Topology also uses physical_chip_mesh_coordinate_mapping_x_of_y.yaml for some multidevice and multi-host runs. In tt-metal, these files are created in ${TT_METAL_HOME}/generated/fabric/ after fabric topology mapping is initialized, then copied into the memory report folder during graph report import. If it is missing, check enable_graph_report in TTNN_CONFIG_OVERRIDES is enabled.

For further information on generating data please refer to TT-Metalium and TT-NN documentation.

To generate reports with other codebases using TT-NN, see the TT-NN Graph Tracing documentation.

Performance reports

TT-NN Visualizer supports the reading of TT-Metalium performance reports. The expected output should be a folder within ${TT_METAL_HOME}/generated/profiler/reports/ containing a profile_log_device.csv file and another csv with the performance results, e.g. ops_perf_results_2024_12_11_11_09_16.csv. A tracy_profile_log_host.tracy file is optional — newer TT-Metal runs may omit it.

Performance report files

Consult the TT-Metalium documentation on how to generate a performance report.

NPE

Network-on-chip performance estimator data can be loaded separately on the /npe route.

Refer to the tt-npe documentation for more details.

Installing from PyPI

TT-NN Visualizer is a standard Python package and can be installed from PyPI with whichever tool you already use.

Using pip (within a virtual environment):

pip install ttnn-visualizer

Using pipx, which installs the app in an isolated environment for you:

pipx install ttnn-visualizer

Or, if you already use uv:

uv tool install ttnn-visualizer

The minimum supported version of Python is 3.10. After installation run ttnn-visualizer to start the application.

Whichever tool you choose, ensure ttnn-visualizer is installed in an isolated/virtual environment and not with the system Python. Having the package installed at the system level and in a virtual environment at the same time can lead to version mismatches. If you run into any issue with an unexpected TT-NN Visualizer version appearing in the browser ensure you have uninstalled the system package.
