aiclk_ppm.h File Reference

#include <stdint.h>
#include <stdbool.h>

Go to the source code of this file.

Data Structures
union	aiclk_targ_freq_info
	Information about the target AICLK frequency decision. More...

Enumerations
enum	aiclk_arb_max {   aiclk_arb_max_fmax ,   aiclk_arb_max_tdp ,   aiclk_arb_max_fast_tdc ,   aiclk_arb_max_tdc ,   aiclk_arb_max_thm ,   aiclk_arb_max_board_power ,   aiclk_arb_max_voltage ,   aiclk_arb_max_gddr_thm ,   aiclk_arb_max_doppler_slow ,   aiclk_arb_max_doppler_critical ,   aiclk_arb_max_host_fmax ,   aiclk_arb_max_count }
	AICLK maximum frequency arbiters. More...
enum	aiclk_arb_min {   aiclk_arb_min_fmin ,   aiclk_arb_min_busy ,   aiclk_arb_min_count }
	AICLK minimum frequency arbiters. More...
enum	targ_freq_reason {   limit_reason_min_arb ,   limit_reason_max_arb ,   limit_reason_fmin ,   limit_reason_sweep ,   limit_reason_forced }

Functions
void	aiclk_update_busy (void)
void	SetAiclkArbMax (enum aiclk_arb_max arb_max, float freq)
void	SetAiclkArbMin (enum aiclk_arb_min arb_min, float freq)
void	EnableArbMax (enum aiclk_arb_max arb_max, bool enable)
void	EnableArbMin (enum aiclk_arb_min arb_min, bool enable)
void	CalculateTargAiclk (void)
void	DecreaseAiclk (void)
void	IncreaseAiclk (void)
void	InitArbMaxVoltage (void)
float	GetThrottlerArbMax (enum aiclk_arb_max arb_max)
uint8_t	ForceAiclk (uint32_t freq)
uint32_t	GetAiclkTarg (void)
uint32_t	GetMaxAiclkForVoltage (uint32_t voltage)
uint32_t	GetAiclkFmin (void)
uint32_t	GetAiclkFmax (void)
uint32_t	get_aiclk_effective_arb_min (enum aiclk_arb_min *effective_min_arb)
uint32_t	get_aiclk_effective_arb_max (enum aiclk_arb_max *effective_max_arb)
uint32_t	get_enabled_arb_min_bitmask (void)
uint32_t	get_enabled_arb_max_bitmask (void)
union aiclk_targ_freq_info	get_targ_aiclk_info (void)
uint8_t	throttler_counter_handler (const union request *request, struct response *response)

Enumeration Type Documentation

aiclk_arb_max

enum aiclk_arb_max

AICLK maximum frequency arbiters.

These arbiters set upper limits on the AICLK frequency. The effective maximum frequency is determined by the lowest enabled arbiter value.

Warning

The order of these enum values must be preserved for compatibility.

Enumerator
aiclk_arb_max_fmax	Maximum frequency limit
aiclk_arb_max_tdp	Thermal Design Power limit
aiclk_arb_max_fast_tdc	Fast Thermal Design Current limit
aiclk_arb_max_tdc	Thermal Design Current limit
aiclk_arb_max_thm	Thermal limit
aiclk_arb_max_board_power	Board power limit
aiclk_arb_max_voltage	Voltage limit
aiclk_arb_max_gddr_thm	GDDR thermal limit
aiclk_arb_max_doppler_slow	Doppler slow throttling limit
aiclk_arb_max_doppler_critical	Doppler critical throttling limit
aiclk_arb_max_host_fmax	Host-adjustable fmax ceiling
aiclk_arb_max_count	Number of max arbiters

aiclk_arb_min

enum aiclk_arb_min

AICLK minimum frequency arbiters.

These arbiters set lower limits on the AICLK frequency. The effective minimum frequency is determined by the highest enabled arbiter value.

Warning

The order of these enum values must be preserved for compatibility.

Enumerator
aiclk_arb_min_fmin	Minimum frequency limit
aiclk_arb_min_busy	Busy state frequency requirement
aiclk_arb_min_count	Number of min arbiters

targ_freq_reason

enum targ_freq_reason

Enumerator
limit_reason_min_arb	We are being limited by a min arbiter
limit_reason_max_arb	We are being limited by a max arbiter
limit_reason_fmin	The aiclk was arbitrated below fmin, and therefore was set to fmin
limit_reason_sweep	The aiclk is random due to sweep being enabled
limit_reason_forced	The aiclk is forced

Function Documentation

aiclk_update_busy()

void aiclk_update_busy

(

void

)

CalculateTargAiclk()

void CalculateTargAiclk

(

void

)

DecreaseAiclk()

void DecreaseAiclk

(

void

)

EnableArbMax()

void EnableArbMax	(	enum aiclk_arb_max	arb_max,
		bool	enable )

EnableArbMin()

void EnableArbMin	(	enum aiclk_arb_min	arb_min,
		bool	enable )

ForceAiclk()

uint8_t ForceAiclk

(

uint32_t

freq

)

get_aiclk_effective_arb_max()

uint32_t get_aiclk_effective_arb_max

(

enum aiclk_arb_max *

effective_max_arb

)

get_aiclk_effective_arb_min()

uint32_t get_aiclk_effective_arb_min

(

enum aiclk_arb_min *

effective_min_arb

)

get_enabled_arb_max_bitmask()

uint32_t get_enabled_arb_max_bitmask

(

void

)

get_enabled_arb_min_bitmask()

uint32_t get_enabled_arb_min_bitmask

(

void

)

get_targ_aiclk_info()

union aiclk_targ_freq_info get_targ_aiclk_info

(

void

)

GetAiclkFmax()

uint32_t GetAiclkFmax

(

void

)

GetAiclkFmin()

uint32_t GetAiclkFmin

(

void

)

GetAiclkTarg()

uint32_t GetAiclkTarg

(

void

)

GetMaxAiclkForVoltage()

uint32_t GetMaxAiclkForVoltage

(

uint32_t

voltage

)

GetThrottlerArbMax()

float GetThrottlerArbMax

(

enum aiclk_arb_max

arb_max

)

IncreaseAiclk()

void IncreaseAiclk

(

void

)

InitArbMaxVoltage()

void InitArbMaxVoltage

(

void

)

SetAiclkArbMax()

void SetAiclkArbMax	(	enum aiclk_arb_max	arb_max,
		float	freq )

SetAiclkArbMin()

void SetAiclkArbMin	(	enum aiclk_arb_min	arb_min,
		float	freq )

throttler_counter_handler()

uint8_t throttler_counter_handler	(	const union request *	request,
		struct response *	response )
