pciesd.h File Reference

#include <stdbool.h>
#include <stdint.h>
#include <stdlib.h>

Include dependency graph for pciesd.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Data Structures
struct	CntlInitV2Param
struct	CntlInitV3Param

Enumerations
enum	PCIeInitStatus {   PCIeInitOk = 0 ,   PCIeSerdesFWLoadTimeout = 1 ,   PCIeLinkTrainTimeout = 2 }
enum	PCIeDeviceType {   EndPoint = 0 ,   RootComplex = 1 }

Functions
PCIeInitStatus	SerdesInit (uint8_t pcie_inst, PCIeDeviceType device_type, uint8_t num_serdes_instance)
void	ExitLoopback (void)
void	EnterLoopback (void)
void	CntlInit (uint8_t pcie_inst, uint8_t num_serdes_instance, uint8_t max_pcie_speed, uint64_t board_id, uint32_t vendor_id)
void	CntlInitV2 (const struct CntlInitV2Param *param)
void	CntlInitV3 (const struct CntlInitV3Param *param)
void	ChangeLinkSpeed (uint8_t pcie_speed)
bool	ArcDmaTransfer (const void *src, void *dst, uint32_t size)

Enumeration Type Documentation

PCIeDeviceType

enum PCIeDeviceType

Enumerator
EndPoint	0
RootComplex	1

PCIeInitStatus

enum PCIeInitStatus

Enumerator
PCIeInitOk	0
PCIeSerdesFWLoadTimeout	1
PCIeLinkTrainTimeout	2

Function Documentation

ArcDmaTransfer()

bool ArcDmaTransfer	(	const void *	src,
		void *	dst,
		uint32_t	size )

ChangeLinkSpeed()

void ChangeLinkSpeed

(

uint8_t

pcie_speed

)

CntlInit()

void CntlInit	(	uint8_t	pcie_inst,
		uint8_t	num_serdes_instance,
		uint8_t	max_pcie_speed,
		uint64_t	board_id,
		uint32_t	vendor_id )

CntlInitV2()

void CntlInitV2

(

const struct CntlInitV2Param *

param

)

CntlInitV3()

void CntlInitV3

(

const struct CntlInitV3Param *

param

)

EnterLoopback()

void EnterLoopback

(

void

)

ExitLoopback()

void ExitLoopback

(

void

)

SerdesInit()

PCIeInitStatus SerdesInit	(	uint8_t	pcie_inst,
		PCIeDeviceType	device_type,
		uint8_t	num_serdes_instance )
