AI Accelerator
Chips4× Blackhole® (2× p300c cards)
Tensix cores480 total (120 per chip)
AI clock1.35 GHz
SRAM720 MB total (180 MB/chip)
DRAM128 GB GDDR6 total (32 GB/chip)
Bandwidth2,048 GB/s total (1,024 GB/s per card)
Chip interconnect800 Gbps between any two chips (internal Samtec ARP6 cable between cards)
Card powerUp to 1,100 W (550 W per card)
Host System
CPUAMD Ryzen 7 9700X (8c, 3.8 GHz)
System RAM256 GB DDR5-5600
Storage4 TB NVMe (PCIe Gen4 x4)
MotherboardASRock B850M-C
OSUbuntu 24.04.3 LTS
PSU1,600 W
Maximum draw1,300 W
Idle power320 W
Connectivity
Display1× HDMI
USB8× (2× Gen2, 2× Gen1, 4× USB 2.0)
LANGigabit Ethernet
WiFiWi-Fi 6 (802.11ax) dual-band
Bluetooth5.3
Physical
Dimensions9.1 × 17.8 × 15.6 in
Weight20 kg / 44 lbs
CoolingLiquid + forced air (38 dBA at max load)
Operating temp10–35°C (50–95°F)
