Specifications, Requirements, and Setup

Package Contents

The Tenstorrent TT-QuietBox Liquid-Cooled Desktop Workstation system package includes:

TT-QuietBox Wormhole (TW-04001)

TT-QuietBox Blackhole (TW-04002)

Tenstorrent TT-QuietBox Wormhole System
C13 Power Cable, 1.8m/6ft.
2x QSFP-DD 400GbE Cable, 0.6m/2ft.
Remote Control for RGB Lighting

Tenstorrent TT-QuietBox Blackhole System
C13 Power Cable, 1.8m/6ft.
Remote Control for RGB Lighting
Networking Cables TBD

WARNING: TT-QuietBox is shipped in a wooden crate weighing a total of 131 lbs. / 59.4 kg. The system itself weighs 96 lbs. / 43.5 kg. We strongly recommend at least two people for moving and uncrating the system.

System Specifications

Specification

TT-QuietBox Wormhole (TW-04001)

TT-QuietBox Blackhole (TW-04002)

CPU

AMD EPYC™ 8124P
(16C/32T, up to 3 GHz, 125W, AMD)

AMD EPYC™ 8124P
(16C/32T, up to 3 GHz, 125W, AMD)

Motherboard

ASRock Rack SIENAD8-2L2T*

ASRock Rack SIENAD8-2L2T*

Memory

512 GB (8x64 GB)
DDR5-4800 ECC RDIMM
(0 Slots Free)

256 GB (8x32 GB)
DDR5-4800 ECC RDIMM
(0 Slots Free)

Storage

4 TB NVMe PCIe 4.0 x4

4 TB NVMe PCIe 4.0 x4

Tensix Processors

4x Tenstorrent Wormhole™ n300 Tensix Processor

4x Tenstorrent Blackhole™ p150c Tensix Processor

Cables

4x Warp 100 Bridge
2x QSFP-DD 400GbE Cable

TBD

Host System
Connectivity

2x RJ45 10GBase-T via Intel® X710
2x RJ45 1GBase-T via Intel® I210
4x USB 3.1 Gen 1 (5 Gbps) Type-A (2x Front, 2x Rear)
1x VGA
1x IPMI

2x RJ45 10GBase-T via Intel® X710
2x RJ45 1GBase-T via Intel® I210
4x USB 3.1 Gen 1 (5 Gbps) Type-A (2x Front, 2x Rear)
1x VGA
1x IPMI

Tensix Processor Connectivity

4x QSFP-DD Active 200G (2 per card)

16x QSFP-DD Passive 800G (4 per card)

Power Supply

1650W 80 PLUS Gold

TBD

Operating System

None

None

Dimensions (System)
(WxDxH)

10” x 21.5” x 20” (96 lbs.)
254mm x 546mm x 508mm (43.5 kg)

10” x 21.5” x 20” (96 lbs.)
254mm x 546mm x 508mm (43.5 kg)

Dimensions (Shipped)
(WxDxH)

18” x 33” x 27” (131 lbs.)
453mm x 839mm x 686mm (59.4 kg)

18” x 33” x 27” (131 lbs.)
453mm x 839mm x 686mm (59.4 kg)

*Early prototypes employed the TYAN Tomcat HX S8040 MB (S8040GM4NE-2T).

Operating System Requirements

The TT-QuietBox system ships without an operating system installed. We recommend installing Ubuntu 22.04 (Jammy Jellyfish) to properly use the Tenstorrent Tensix Processors.

QSFP-DD Connections and System Topology

Blackhole™ p150c Version (TW-04002)

The Tenstorrent TT-QuietBox Blackhole (TW-04002) includes four Blackhole™ p150c Tensix Processors and external QSFP-DD cables that enable the Tensix Processor mesh.

This specification is still being finalized and will be added at a later date.

Wormhole™ n300 Version (TW-04001)

The Tenstorrent TT-QuietBox Wormhole (TW-04001) includes four Wormhole™ n300 Tensix Processors and internal Warp 100 bridges and external QSFP-DD cables that enable the Tensix Processor mesh.

The TT-QuietBox ships with the Warp 100 bridges connected, but the two QSFP-DD cables will need to be connected by the customer. This diagram displays the system topology and how the cards are enumerated, along with where the Warp 100 bridges are connected and where the included QSFP-DD cables need to be connected.

One QSFP-DD cable will need to be connected to Port 1 on the cards in Slots 1 and 4.

One QSFP-DD cable will need to be connected to Port 2 on the cards in Slots 3 and 2.

Environment Specifications

The TT-QuietBox Liquid-Cooled Desktop Workstation is designed to operate at up to 35°C/95°F external ambient temperatures.

Lighting Control

The TT-QuietBox uses a Bitspower RF Remote Controller Hub to control the lighting and the remote is included with the system. For details on how to operate it, please review the Bitspower documentation here.

Software Setup

Instructions on how to set up software on TT-QuietBox are available here.
